Vented Recycling Extruder

Model	SCREW DIA (mm)	L/d Ratio	SCREW RPM	TOTAL LOAD (KW) MAIN MOTOR (KW)	PRODUCTION Kg/hr.	DIMENSION L/W (MM)
CVT90 R32	90	32/1	55	45 / 22	100-120	10100/1850
CVT100 R29	90	29/01	55	70 / 30	125-150	10155/1900
CVT100 R32	100	32/1	55	75 / 30	125-150	10455/1900
CVT100 R36	100	36/1	55	80 / 30	125-150	10855/1900
CVT100 R36 DV	100	36/1 Double Vent	60	80 / 30	140-160	10855/1900
CVT115 R32	115	32/1	55	90 / 37	175-190	10985/2000
CVT115 R36	115	36/1	55	95 / 37	175-190	11450/2000
CVT115 R36 DV	115	36/1 Double Vent	60	105 / 45	190-220	11450/2000
CVT120 R29	120	29/1	55	105 / 55	200-225	10785/2000
CVT125 R29	125	29/1	55	130 / 75	250-275	10980/2200
CVT125 R32	125	32/1	55	135 / 75	250-275	11955/2200
CVT140 R29	140	29/1	55	160 / 90	325-350	12245/2350

                        Model
                          SCREW DIA
(mm)

                          L/d Ratio
                          SCREW RPM
                          TOTAL LOAD (KW)
 MAIN MOTOR (KW)

                          PRODUCTION

  Kg/hr.
                          DIMENSION

  L/W (MM)



CVT90 R32

32/1

45 / 22

100-120

10100/1850

CVT100 R29

29/01

70 / 30

125-150

10155/1900

CVT100 R32

100

32/1

75 / 30

125-150

10455/1900

CVT100 R36

100

36/1

80 / 30

125-150

10855/1900

CVT100 R36 DV

100

36/1
Double Vent

80 / 30

140-160

10855/1900

CVT115 R32

115

32/1

90 / 37

175-190

10985/2000

CVT115 R36

115

36/1

95 / 37

175-190

11450/2000

CVT115 R36 DV

115

36/1
Double Vent

105 / 45

190-220

11450/2000

CVT120 R29

120

29/1

105 / 55

200-225

10785/2000

CVT125 R29

125

29/1

130 / 75

250-275

10980/2200

CVT125 R32

125

32/1

135 / 75

250-275

11955/2200

CVT140 R29

140

29/1

160 / 90

325-350

12245/2350

Vented Recycling Extruders | Advanced Plastic Recycling Solutions

High-Performance Vented Recycling Extruders for Sustainable Material Processing.

Transform your plastic waste into valuable resources with our industry-leading vented recycling extruders. Engineered for maximum efficiency, reliability, and environmental compliance, our systems deliver superior performance for recycling operations of all sizes.

Why Choose Our Vented Recycling Extruder Technology?

Efficient Degassing Technology: Our advanced venting systems effectively remove moisture, volatiles, and contaminants during the extrusion process, ensuring higher quality recycled materials that meet the most demanding specifications.

Superior Processing Capabilities

Process highly contaminated post-consumer plastics
Handle high-moisture content materials
Achieve excellent melt homogenization
Produce consistent pellet quality batch after batch

Cost-Effective Recycling Solutions

Reduce energy consumption by up to 25%
Minimize maintenance requirements
Increase throughput for better ROI
Lower your carbon footprint while maximizing profits

Technical Specifications and Features

Key Components:

Robust gearbox designed for high-torque applications
Precision-engineered screws and barrels for optimal performance
Multiple venting ports for effective degassing
Advanced heating and cooling systems for precise temperature control
State-of-the-art control systems with user-friendly interface

Available Configurations:

Processing capacities from 100 kg/hr to 500 kg/hr
Single-stage and cascade systems
Customizable screw designs for specific polymer types
Integration with washing lines and downstream equipment

Applications Across Industries

Post-consumer plastic recycling facilities
In-house industrial scrap recovery
Film and fiber recycling operations
Bottle-to-bottle recycling systems
Compounding with recycled materials

Expert Support and Service

Comprehensive installation and training
Preventive maintenance programs
Rapid response technical support
Spare parts availability
Process optimization consultations

Ready to Transform Your Recycling Operation?

Contact our technical team today for a personalized consultation on how our vented recycling extruders can revolutionize your plastic recycling process.

Request a Quote
